| Customization: | Available |
|---|---|
| Structure: | Single End |
| Pressure: | ≤2.0 MPa |
| Quantity: | |
|---|---|
Working Conditions
Mediums: Chemical, Food, Oil, Petroleum, Pharmaceuticals Paper and pulp, Sewage treatment
Temperature: Elastomer Dependent
Pressure: ≤2.8MPa
Speed: ≤35m/s
Materials
Stationary Ring: Carbon/Sic/SSic/TC
Rotary Ring: Sic/SSic/TC
Secondary Seal: Rubber/EPDM/Chemraz/Kalrez/Aflas, etc.
Spring and Metal Part: Stainless Steel/Hast C
| Material And Component Codes | ||
| Description | Material | Material Feature & Suitable Scope |
| Rotary /Stationary Face | Carbon | Resistant against: erosive heat. suitable for water and oil medium. |
| Ceramic | Resistant against:shore hardness,abrasion. Suitable for dusted water and oil | |
| Silicon Carbide | Resistant against:heat,abrasion,erosive. Suitable for industrial pumps, submersible pump sewage pump etc | |
| Tungsten carbide | Resistant against:heat,abrasion,erosive. Suitable for industrial pumps, submersible pump sewage pump etc | |
| Bellow Cup gasket Oring | NBR | Resistant against:pressure,abrasion,high elasticity and mechanical strength. Suitable for water and Oil Under -20°C-120°C |
| EPDM | Resistant against:heat freeze,chemical reagent depending. Suitable for water and Oil Under -40°C-150°C | |
| MVQ | Resistant against:heat, oil, reagent, medicine, acetone. Suitable for high temperature. Hydraulic equipment and vacum equipment Suitable for erosive medium under -20°C-180°C | |
| ECO | Resistant against:ozone aging merely ocetum, ammomia ethanol. Suitable for medium -40°C-150°C | |
| SUS304 SUS316 | Resistant against: freon, rock oil. Suitable for medium -30°C-130°C | |
| Retainer driver ring\spring Spring seat | SUS304 SUS316 | Resistant against: abrasion, antirust of feature |
| Metal Materials | |||
| Type | Material Description | Symbol | Code |
| Noral Stainless Steel | 2Cr13 | F2 | |
| Stainless Steel | 304 | F | |
| Stainless Steel | 304L | F1 | |
| Stainless Steel | 316 | G | |
| Stainless Steel | 316L | G1 | |
| Hastelloy C-4 Alloy | Hast C4 | M | |
| Hastelloy B-2 Alloy | Hast B2 | M1 | |
| Carpenter | Carp.20 | M3 | |
| Monel | Monel.K50 | M4 | |
| Hastelloy C-4C-276 Alloy | Hast.C-276 | M5 | |
| Pure Titanim | TA2 | T2 | |
| Carpenter | Carp.42 | T4 | |
| Deposit induration Stainless Steel | Am350 | T6 | |
| 08F Coated with Chrome | Q235-A | C | |
| Brass | H62 | H | |
| Secondary Seal Materials | |||
| Type | Material Description | Symbol | Code |
| Rubber | Nitrile(NBR) | NBR | P |
| Ethylene Propylene(EPDM) | EPR | E | |
| Fluorocarbon Rubber | FPM | V | |
| Silicon Rubber | SI | S | |
| Chloroprene Rubber | CR | N | |
| Hydrogen Nitrile | HNBR | H | |
| Perfluoroelastomer(Kalrez.Chemraz) | FFKM | K | |
| PTFE | Pure PTFE | PTFE | T |
| PTFE, glassfibre reinforced | T2 | ||
| PTFE,Carbon Reinforced | T3 | ||
| PTFE Wrapped | FPM,with PTFE wrapped | PTFE+FPM | M1 |
| EPR,with PTFE wrapped | PTFE+EPR | M2 | |
| MVQ,with PTFE wrapped | PTEF+MVQ | M3 | |
| Expended graphite | Expanded Graphite | G | |
| Seal Ring Materials | |||
| Type | Material Description | Symbol | Code |
| SIC | Silicon Carbide,Sintered Pressureless | SSIC | Q1 |
| Silicon Carbide,Sintered Pressureless(shrunk-in) | Q12 | ||
| Silicon Carbide,Reaction bonded | RBsic | Q2 | |
| Silicon Carbide,Reaction bonded(shrunk-in) | Q22 | ||
| Reaction Silicon Carbide with graphite | Q3 | ||
| Sintered Silocon Carbide with SB | Q4 | ||
| AL203 | Ceramic(Alumina) | 99.5% AL203 | V |
| Ceramic(Alumina) | 99% AL203 | V1 | |
| Ceramic(Alumina) | 95% AL203 | V2 | |
| Cermet | Fe+AL203 | V3 | |
| Co-binder Tungsten Carbide | YG6,GY8 | U1 | |
| Co-binder Tungsten Carbide(shrunk-in) | U12 | ||
| Ni-binder Tungsten Carbide | M106,M108 | U2 | |
| Ni-binder Tungsten Carbide(shrunk-in) | U22 | ||
| NiCrmo-binder Tungsten Carbide | W7 | U3 | |
| NiCrmo-binder Tungsten Carbide(shrunk-in) | U32 | ||
| Crabon | Antimony Impreg,Carbon Graphite | A | |
| Babbit Alloy Impreg,Carbon Graphite | A1 | ||
| Copper Alloy Impreg,Carbon Graphite | A2 | ||
| Resin Impreg Impreg,Carbon Graphite(Furan) | B | ||
| Resin Impreg Impreg,Carbon Graphite(Epoxy) | B1 | ||
| Resin Impreg Impreg,Carbon(Phedol-formaldehyde) | B2 | ||
| Metal | Hot-pressing Carbon | B5 | |
| Stainless Steel | 304 | F | |
| Stainless Steel | 304L | F1 | |
| Stainless Steel | 316 | G | |
| Stainless Steel | 316L | G1 | |
| Tin bronze | ZQSn6-6-3 | S1 | |
| High silicon cast iron | S2 | ||
| High nickel cast iron | S3 | ||
| Plastic | PTFE, glassfibre reinforced | Y1 | |
| PTFE, carbon reinforced | Y2 | ||
We have large stock, so our delivery is very fast.
For example,if products are standarded, the delivery time is one week.
Our company and factory addrss: Ningbo City, Zhejiang Province,China.
Our city has a large port and an airport, so its transportation is very convenient.
Question 1: Are you a factory or a trade company?
Answer: We are a factory and have our top sales for the trade service.
Question 2: What is the minimum order quantity for each order?
Answer: For products of regular models, the minimum order quantity is at least five. We welcome you to test the quality of our products and our services through small orders and look forward to long-term cooperation with you next.
Question3: What is your company's service tenet?
Answer: Quality first, service upmost. We promises that if there is any problem with the quality of the product or if the product is damaged during the transportation, our company will be responsible for compensation, regardless of the ordder turnover value.
Question4: What are the prices of your products?
Answer: For each model, the unit price is listed on the website, but what is indicated on the website is only the average market price. For specific models, you can contact us for price consultation and negotiation.
Question5: Can I try to get a SAMPLE before the order?
Answer: Sure. Our company provides you with samples for free, but you will have to pay for the international delivery (freight collect payment).
